DENAFRIPS TERMINATOR 15TH
แบรนด์: DENAFRIPS
209,900 ฿
Terminator 15th: Complete Digital / Analog IsolationTERMINATOR 15th features complete isolation between its Digital Processing Board and its R-2R ladder network arrays, the two sections physically linked only through the OCXO module.
That isolation is designed to minimize noise crossing between the digital and analog domains, enhancing the converter’s overall signal-to-noise ratio.
That isolation is designed to minimize noise crossing between the digital and analog domains, enhancing the converter’s overall signal-to-noise ratio.
Terminator 15th: Dual Oven-Controlled Crystal OscillatorsTERMINATOR 15th is equipped with dual OCXOs running at 45.1584 MHz and 49.152 MHz, delivering ultra-low phase noise and exceptional timing accuracy across both common audio clock families.
Both OCXOs are housed in a metal casing and powered by a specially designed, shielded power supply, keeping their timing stable regardless of what else is happening elsewhere in the chassis.
Both OCXOs are housed in a metal casing and powered by a specially designed, shielded power supply, keeping their timing stable regardless of what else is happening elsewhere in the chassis.
Terminator 15th: Adaptive FIFO Buffer ReclockingAn adaptive FIFO buffer stores incoming digital audio data, which is then read out using the ultra-low phase noise OCXOs rather than the timing of the original source device.
That reclocked data is converted to analog by true balanced R-2R ladder network arrays built from high-precision resistors chosen for linearity, with a high-precision OCXO clock-out also available to synchronize external audio frequencies at 44.1kHz and 48kHz.
That reclocked data is converted to analog by true balanced R-2R ladder network arrays built from high-precision resistors chosen for linearity, with a high-precision OCXO clock-out also available to synchronize external audio frequencies at 44.1kHz and 48kHz.
Terminator 15th: Brushed Aluminum, Classic DimensionsThe TERMINATOR 15th chassis is meticulously crafted from high-quality brushed aluminum in silver or black, its classic dimensions built to integrate seamlessly into any high-end audio setup.
At 385 x 435 x 110mm and 18kg, it carries the same true balanced R-2R plus DSD conversion architecture as the rest of Denafrips’ Terminator line, backed by a 12-month warranty.
At 385 x 435 x 110mm and 18kg, it carries the same true balanced R-2R plus DSD conversion architecture as the rest of Denafrips’ Terminator line, backed by a 12-month warranty.
